Air Lift ICON Vehicle Dynamics Stage 8 Suspension System 1.25-3.5" Lift | 2022-2026 Toyota Tundra - KITICOK53198T

Air Lift ICON Vehicle Dynamics Stage 8 Suspension System 1.25-3.5" Lift | 2022-2026 Toyota Tundra - KITICOK53198T

The 3rd Gen Toyota Tundra ICON Vehicle Stage 7 is the Big Shock System featuring 2.5 Remote Reservoir front Coilovers and 2.5 Remote Reservoir rear shocks, UCA's along with upgraded rear lower trailing arms.

Stage 8 helps to free up the rear suspension movement while gaining strength and ground clearance with the addition of ICON rear lower suspension links. Available in either billet or tubular versions these links employ dual-durometer greaseless bushings at one end, and a massive FK rod end at the other to provide the best combination of free articulation and ride quality. The billet lower links provide the additional benefits of on-vehicle adjustability and replaceable rock skids.

Get up to 40% more travel versus stock! ICON's Billet or Tubular Upper Control Arms to squeeze every inch of travel out of the Tundra's suspension while increasing available lift height to 1.25 to 3.5" (front). ICON UCA's are optimized for lifted or leveled trucks, with caster adjustment built into the geometry of the arm, making it easier to dial in your truck's steering alignment. These UCA's feature ICON's proprietary Delta Joint Pro, which is fully serviceable and provides up to 90-degrees of movement to allow bind-free movement throughout the full range of suspension travel afforded by the ICON coilovers. Get increased rear shock performance to match the 2.5 front coilovers. Stage 7 includes ICON's 2.5-inch diameter VS Series rear shock absorbers with remote reservoirs, for a massive increase in shock oil volume and surface area for heat dissipation to help prevent cavitation and maintain damping performance over long stretches of rough terrain. In addition, the 2.5 VS rear shocks feature 7/8" rods and other beefier components to handle the long travel and punishing cycle rates of moving fast across the terrain.

Features

• Adjustable 1.25-3.5" of Front Lift
• 2.5 Aluminum Series front coilover shock
• 7/8” diameter induction hardened, chrome plated shock shaft.
• 2.5” diameter monotube design.
• Fitment for up to  35" tires (larger tires may fit with minor fender trimming and modifications)
• TIRE & WHEEL: 35X12.50 ON 8.5" WIDE WHEEL W/ 5.75" BACKSPACE (MINOR TRIMMING REQUIRED)
• Improved suspension performance and ride quality over stock
• Vehicle specific tuned front and rear shocks for superior damping and vehicle control
• PTFE lined bearings for extended longevity and minimal deflection
• 6061 Aircraft grade aluminum CNC machined components with a black anodized finish
• 100% Bolt-on system - no drilling, cutting, or welding necessary for install
• Tubular or billet UCA for added strength, durability and an additional degree of caster (Select Stages)
• UCAs feature the Delta Joint Pro with 90 degrees of total articulation (Select Stages)
• Vehicle specific design.
• Vehicle specific tuned for superior shock damping and control
• CNC machined 6061 aluminum components
• 100% Rebuildable and revalveable
• Fits: 2022+ Toyota Tundra

What our Experts Think

Q&A

Q: What vehicles does the ICON Vehicle Dynamics KITICOK53198T fit?
A: This Stage 8 suspension system is designed for 2022–2026 Toyota Tundra models with compatible suspension configurations.

Q: How much lift does the ICON Stage 8 kit provide?
A: The system provides an adjustable 1.25–3.5 inches of lift, allowing you to customize ride height, ground clearance, and vehicle stance.

Q: What is included in the ICON Stage 8 suspension system?
A: The kit includes ICON performance suspension components engineered to improve ride quality, handling, and off-road capability for Toyota Tundra applications.

Q: What are the benefits of the ICON Stage 8 system?
A: It enhances suspension performance, improves off-road control, increases clearance for larger tires, and provides a more capable setup for daily driving and adventure use.

Q: Can I install larger tires with this lift kit?
A: Yes. The added lift clearance supports larger wheel and tire combinations. Final fitment depends on tire size, wheel offset, and vehicle configuration.

Q: Is the ICON Stage 8 kit suitable for daily driving?
A: Yes. ICON suspension systems are designed to deliver improved off-road performance while maintaining comfortable on-road drivability.

Q: Does this kit improve off-road performance?
A: Yes. The upgraded suspension components help improve articulation, stability, damping control, and overall capability on challenging terrain.

Q: Does this lift kit increase towing or payload capacity?
A: No. A suspension lift changes ride height and handling characteristics but does not increase the Toyota Tundra’s factory towing or payload ratings.

Maintenance Tips

• Inspect coilovers, shocks, control arms, brackets, and mounting hardware regularly for wear or damage.
• Check all bolts, nuts, and fasteners periodically to ensure proper torque and security.
• Keep suspension components clean and free from dirt, mud, salt, and road debris.
• Inspect suspension parts after off-road driving, towing, or heavy loads for signs of stress.
• Check for unusual noises, vibrations, or changes in ride quality.
• Maintain proper wheel alignment to promote even tire wear and improve handling.
• Inspect tires regularly and maintain recommended tire pressure.
• Verify suspension clearance and check for rubbing or interference with tires and steering components.
• Inspect bushings, joints, and control arm components for wear or looseness.
• Service shocks and suspension components according to manufacturer recommendations.
• Avoid exceeding your Toyota Tundra's manufacturer-rated GVWR and suspension limits.
