Goodman - 2.5 Ton/60,000 BTU Ultra-Low NOx Gas Packaged Unit - 13.4 SEER2 - Single Stage - R32 - 230V - GPUM33006031

Goodman - 2.5 Ton/60,000 BTU  Ultra-Low NOx Gas Packaged Unit - 13.4 SEER2 - Single Stage - R32 - 230V - GPUM33006031

The Goodman GPUM33006031 is a gas heat and electric AC packaged unit, ready for any application where it is not convenient to have an indoor furnace or air handler. At 13.4 SEER2 and 81% AFUE, the GPUM33006031 is an inexpensive option with a standard efficiency designed for rooftop and next-to-building applications.

Features

• 2.5 ton, 60,000 BTU packaged unit
• 13.4 SEER2, 81% AFUE
• Downflow or horizontal discharge installation options
• Fully charged and ready to install
• Low sound output
• Ultra-Low NOx compliant


Specifications

Manual

• GPUM3 Installation Manual
• GPUM3 Specifications Sheet
• GPUM3 Service Manual
• GPUM3 Replacement Parts Manual


What our Experts Think

• Ultra-Low NOx: Environmentally friendly design reduces harmful emissions.

• Efficient Cooling & Heating: 13.4 SEER2 with 2.5 Ton / 60,000 BTU output for reliable year-round comfort.

• Single-Stage Performance: Provides consistent and dependable operation.

• Eco-Friendly Refrigerant: Uses R32 to minimize environmental impact.

• Durable Design: Built to withstand long-term use in varied climates.

• Power Supply: 230V compatible for standard residential installations.

• Quiet Operation: Engineered for minimal operational noise.

Q&A

Q: What type of HVAC system is this?
A: This is a self‑contained gas & electric packaged unit, combining both air conditioning and natural gas heating in one rooftop or ground‑level outdoor cabinet — no separate indoor furnace or air handler needed.

Q: What are the cooling and heating capacities?
A: The unit delivers 2.5 tons (≈28,600 BTU) of cooling at 13.4 SEER2 and 60,000 BTU of natural gas heating — providing year‑round comfort.

Q: How efficient is it?
A: It features 13.4 SEER2 (cooling) and ≈81% AFUE (heating) for efficient performance aligned with modern standards.

Q: What does “Ultra‑Low NOx” mean?
A: The unit is compliant with ultra‑low NOx emissions standards, producing reduced nitrogen oxide for cleaner operation and improved environmental compliance.

Q: What refrigerant does this use?
A: It’s precharged for R‑32 refrigerant, a newer low‑GWP cooling agent.

Q: What installation configurations are supported?
A: Supports downflow or horizontal discharge, making it suitable for rooftop and next‑to‑building setups.

Q: What are the electrical requirements?
A: Operates on 208/230 V single‑phase power (60 Hz).

Q: What type of compressor and airflow system does it include?
A: Includes a single‑stage scroll compressor and a multi‑speed blower motor for reliable cooling airflow.

Q: How quiet is the unit?
A: Runs around ~78 dBA, typical for packaged HVAC units.

Q: What size breaker is recommended?
A: Requires about 22.8 A minimum circuit and up to a 35 A breaker for proper protection.

Maintenance Tips

• Replace air filters every 1–3 months to maintain airflow and efficiency.

• Keep supply and return vents clear of furniture, dust, and debris.

• Maintain 2–3 feet of clearance around the unit for proper airflow and safe operation.

• Inspect the condensate drain line regularly to prevent clogs and water damage.

• Check thermostat settings and operation to ensure proper heating and cooling cycles.

• Examine vent pipes, ductwork, and connections for leaks or blockages.

• Clean blower compartment and internal surfaces to reduce dust buildup.

• Inspect burners and heat exchanger periodically for safe operation and efficiency.

• Listen for unusual noises such as rattling, buzzing, or humming indicating potential mechanical issues.

• Schedule annual professional HVAC maintenance to inspect gas connections, refrigerant levels, electrical components, and safety controls.
