SCM 7.5 HP Spindle Shaper w/ Tilting Spindle - SS512TB

SCM 7.5 HP Spindle Shaper w/ Tilting Spindle - SS512TB

$9,922.99
$9,922.99 $13,230.00
SAVE 24% Sold out
SCM 7.5 HP Spindle Shaper w/ Tilting Spindle - SS512TB

SCM 7.5 HP Spindle Shaper w/ Tilting Spindle - SS512TB

$9,922.99
$9,922.99 $13,230.00
SAVE 24% Sold out

SCM 7.5 HP Spindle Shaper w/ Tilting Spindle - SS512TB

The Cantek SS512TB tilting spindle shaper is a ruggedly built shaper with refined features well suited for demanding production environments.  Its’ versatile design makes it the ideal shaping solution for edge-profiling, door & furniture components, mouldings, tenoning, and more.  The powerful dual direction 7.5HP driven spindle allows for optimum shaping even with large profiles.  The heavy-duty cast-iron table and shaping column ensure maximum stability with superior vibration damping for optimum finish quality.

Features
  • Tilting spindle from -5° to +45°
  • 1-1/4” interchangeable spindle is standard (other sizes available)
  • Large cast-iron table is ground and polished for maximum stability and durability
  • Powerful 7.5 HP motor for even the most demanding profiling work
  • Five spindle speeds can be easily adjusted to suit your tool diameter
  • Electronic spindle brake for added safety and facilitates with fast changeover
  • Precision fence assembly with micro infeed and outfeed fence adjustment
  • Finger style fence allows fence to be adjusted around the cutter for added safety and workpiece stability
  • Cast iron ground & polished table with insert rings & t-slot for mitre / tenoning jig
  • Precision ground and electronically balanced spindle
  • V-belt drive with (5) spindle speeds is easily accessed from the front of the machine (3/4/6/8/1000 RPM)
  • Electric spindle brake for added safety
  • Spindle lock – with limit switch safety, machine will not start with lock engaged
  • Micro spindle height adjustment with dial indicator for precise height adjustment
  • 1-1/4” Interchangeable cutter spindle is standard
  • Forward/reverse spindle rotation
  • Adjustable “finger” type fence
  • Independent micro-fence adjustment on both sides
  • Plug to accept Cantek Power Feeder and table is pre-drilled for mounding feeder base
  • 1-1/4” spindle
  • (1) 5” dust chute on guard & (1) 4” dust chute in the table
  • Safety guard
  • Mitre tenoning jig
What our Experts Think
  • Powerful 7.5HP motor delivers the strength needed for demanding shaping, profiling, and production woodworking applications.
  • Tilting spindle capability adds versatility, allowing complex profiles, angled cuts, and specialty moulding operations with greater precision.
  • Ideal for doors, windows, cabinetry, furniture, and architectural millwork production.
  • Provides smooth, accurate shaping results while maintaining excellent control and repeatability.
  • Heavy-duty SCM construction ensures stability, reduced vibration, and reliable long-term performance.
  • An excellent choice for professional woodworkers and manufacturers seeking versatility, precision, and high-production shaping capabilities.
Q&A

Q: What is the SCM SS512TB used for?
A: The SS512TB is designed for precision shaping, profiling, edge forming, and joinery operations in professional woodworking applications.

Q: What are the benefits of the tilting spindle?
A: The tilting spindle allows angled cutting and complex profile creation, increasing versatility and expanding machining capabilities.

Q: How does the 7.5 HP motor improve performance?
A: The powerful 7.5 HP motor delivers consistent cutting power for demanding shaping operations and large cutter tooling.

Q: Is the SS512TB suitable for cabinet and furniture production?
A: Yes, it is ideal for producing mouldings, doors, windows, furniture parts, and custom wood profiles.

Q: Why choose the SCM SS512TB?
A: It offers powerful performance, precise shaping accuracy, versatile tilting spindle functionality, and reliable operation for professional woodworking environments.

Maintenance Tips
  • Clean the spindle, table surface, fences, and dust collection areas after each use.
  • Inspect shaper cutters and tooling regularly for wear, damage, or dull cutting edges and replace as needed.
  • Ensure spindle nuts, tool holders, and cutter assemblies are securely tightened before operation.
  • Check tilting spindle mechanisms and angle settings regularly for smooth, accurate adjustment.
  • Lubricate bearings, elevation systems, and moving components according to SCM maintenance guidelines.
  • Inspect the 7.5 HP motor, drive belts, and electrical connections for wear or overheating.
  • Verify fence alignment and spindle positioning to maintain precise cutting results.
  • Keep the dust extraction system clean and functioning efficiently to reduce debris buildup.
  • Tighten loose hardware, guards, and adjustment controls during routine inspections.
  • Follow SCM’s preventive maintenance schedule to maximize machining accuracy, tooling life, and machine reliability.
View full details
