Reliable temperature control and effortless timer management are the foundation of any great sauna experience. Our digital sauna control panels bring both together in a single refined unit — built to oversee heater operation with consistent precision. Each countdown timer ensures the sauna shuts off automatically after your chosen session length, while the adjustable temperature control lets you dial in the heat you prefer with confidence.
These panels are designed to be instantly familiar and easy to operate, yet they house a remarkably capable engine underneath. Our controls can be configured to fit virtually any sauna scenario — residential or commercial — with a wide range of recommended settings that can be refined further to match specialized needs. For traditional, infrared, and steam installations up to 240 volts, single or three phase, the control can drive heater loads of up to 60 amps. For larger commercial rooms, high-capacity contactors can be added externally to extend that reach. Temperature ranges and preset presets can also be tuned to your preference.
Horizontal Model Up to 7 Push-Buttons
- CONTROL / ON-OFF
- TIME UP
- TIME DOWN
- TEMPERATURE UP
- TEMPERATURE DOWN
- USER PRESET or FAN (optional relay contact)
- LIGHT ON / OFF (optional relay contact)
- RADIO / CD ON / OFF (optional relay contact)
- PREHEAT or DELAY-BEFORE-START up to 100 hours
Finishes: Available in Black, White, or Custom labels.
Metal Face: 2-gang, 4.5" x 4.5" x 1/4" (114mm x 114mm x 6mm)
Vertical Model Up to 9 Push-Buttons
The vertical layout offers the same advanced button set in a slimmer profile, ideal for tight wall placements or when a cleaner vertical footprint suits your room design.
Metal Face: 2-gang, 6.5" x 4.5" x 1/4" (165mm x 114mm x 6mm)
Available in Black, White, or Custom labels to match your room finish.
SMART SAUNA WiFi Control
Operate your sauna from your phone, tablet, or computer with the Smart Sauna WiFi interface. No app installation is required — the control runs through a clean web interface that works across devices.
- Connect via WiFi or Ethernet cable
- Operate remotely from anywhere in the world
- Use your local WiFi home network
- Works through any WiFi Access Point
No Power Box Needed for Most Applications
Control Panel Specifications
Customize Your Sauna Controls
Upgrade to a new sauna control panel for optimal sauna settings. Personalize your sauna with our advanced control panel. Sauna manufacturers and installers can request custom features and specifications. We offer custom-designed face decals with company logos and special designations. Both horizontal and vertical panel form factors are available, and a wide range of colors and finishes can be accommodated. Indicator LED display is red. Green or blue can be different for time and temperature. Large push-buttons make them easy to operate — user friendly. Customized temperature and timer ranges. Easy installation.
Applications
Examples of Custom Face Labels
Features
- Accurate digital temperature and time control
- Sensor wire up to 50ft / 15m
- Accumulated operating time memory option
- Preset memory
- Auto-on with calibration
- Programmable time and time-out limits
- Large LED display
- Large push-buttons
- Quiet operation
- Powerful internal relays
- Sealed unit housing
- Supply and load can be different voltage
- Message on display when error detected
Options
- Remote control panel with display
- Extended temperature ranges
- Extended timer ranges
- Special custom functionality
- Up to 2 additional internal relays
- Variety of temperature sensors
- Programmable temp and timer limits
- Power-on cycle LED display
- Additional input for external contact
- Additional output for external LED lamp
- Two-stage push-buttons
- Custom-designed face label
- Optional internal buzzer
Programmable Operating Setpoints
- Minimum and maximum temperature limit
- Minimum and maximum timer limit
- Pre-heating or standby temperature
- Delay-before-start timer preset
- Fahrenheit or Celsius units
- Multiple preset points
- Room or fill-wall period
Programmable Control of Outputs
- High power relay 1 control (30 Amp)
- High power relay 2 control (30 Amp)
- Medium power relay 3 control (15 Amp)
- Medium power relay 4 control (15 Amp)
- Active relay indication
- Manual and automatic relay control
- Relay contacts isolated from each other
Temperature Sensor Probes
Every control ships ready to communicate with a precision sensor probe. Flush-face controller installations use an optional remote panel, while semi-flush installations with wall or panel mount give you additional remote control options. Wiring extensions up to 50ft / 15m are supported out of the box, with extended runs available on request.
Examples of available models include wiring extensions up to 50ft / 15m. Semi-flush face installations come standard with optional remote control panel connectivity, and every probe is tuned to deliver the stable, repeatable readings that precision temperature control depends on.
Temperature Sensor Protection
Optional Plate-Guard
For standard sensor probes. Plastic model PPS-4 and SS model PPS-4.
Optional Plastic Guard
For standard sensor probes. Model PS-5.
Temperature Sensor
With flange mount for panel integration.
Model PRS-10LED
Sauna remote START / STOP button with LED indicator.
Control Panel Wiring Examples
More wiring examples for SD-4 controller
Simple SD-4PB Wiring
For up to 30 Amps load.
SD-4PB with Contactor
For very high loads.
Extended SD-4PB Wiring
For up to 60 Amps loads in two banks.
SD-4PB Wiring
With additional light or fan control.
Sauna Control Operation
SD-4PB is a digital temperature and time sauna controller designed for heating and/or cooling. It features an internal, accurate, programmable thermostat processor that is self-calibrating and does not require any maintenance or adjustments. The internal thermostat processor is wired digitally and runs directly from the included thermostat operation information for a preset period of time, depending upon the model, in seconds, minutes, hours or days.
While the timer is running, the thermostat controls the on-board relays. Standard models have two high-power relays, each rated up to 30 Amps 250Vac load max. Optionally an internal alarm buzzer or up to two additional relays can be ordered for special applications to control loads of up to 15Amps 250Vac max each.
The high power and the optional relays' contacts can be wired up to control heaters, HVAC systems and other loads like a fan, motor, pump, etc. The supply power and the load voltages are isolated from each other. The two voltages can be equal (single phase) or different (split) — from each other but must not exceed the controller maximum permitted rating.
In order to switch very high loads, the relay contacts can be wired up to control the coils of external contactors. Once extended, the controller and its wiring do not need to carry the high load current. The sauna control unit is enclosed in a sealed enclosure, and the included cable length can be extended by splicing the corresponding wires to a premium low-voltage cable.
A variety of the controller's operating configurations, temperature and timer ranges and limits are also programmable via the front side menu. In customized face plates the controller can have up to 9 push buttons. The SD-4PB controls the heating element or contactor based on the current temperature, the timer count, and other indicators of operation. The LED display can be ordered in RED, GREEN or BLUE color. Another option is an external Remote Control Panel — Model SD-4RC — that can be connected to the main panel via a 4- or 6-conductor cable up to 50ft / 15m away. Now, the SD-4PB sauna controllers are designed to eliminate almost completely the EMF (Electro-Magnetic Field) radiation.
